SPECIFICATIONS
DECK
W 4.5″ x L 19″ / W 11.50cm x L 48.30cm
T6 Heat Treated Aluminium Boxed Channel Deck
Press Fit Headtube
Front and Rear Nylon Deck Block Inserts
NECK
Slamm Exclusive Extruded Coffin Connector
BAR
19.5” x19.5” One Piece Steel T Bar
CLAMP
Double Clamp Anodised Finish
HEADSET
Pressed Semi-Sealed Threadless Headset
Threadless Internal Hidden Compression (IHC) System
FORK
Slamm Steel Fork Two-Sided Print Threadless
Accepts 110mm Wheels
GRIPS
135mm Team Grips with Impact Resistant Bar Ends
WHEELS
PU Casted 110mm x 24mm
88A High Rebound Urethane
50/50 Fade PU With One-Sided Wheel Print
BEARINGS
ABEC-9 Chrome Bearings with Black Rubber Shield
RECOMMENDED AGE
8+ Years
MAXIMUM RIDER WEIGHT
100kg
OVERALL DIMENSIONS
Height: 29.5” / 75cm
Length:26.7” / 68cm
Width: 19.9” / 50.5cm
Ride Height: 27.1” / 69cm
Ride Height is between the top of the deck and the top of the bar grips
TEST STANDARDS
EN14619
